Clean Tunnel Oven G-C5000
The Clean Tunnel Oven G-C5000 is a high-performance continuous drying and curing system specially designed for 3C electronic products after dispensing and adhesive coating processes. The equipment provides a clean Class 1000 production environment, precise temperature control, and stable conveyor transportation to ensure reliable drying quality and reduce defects during electronic component manufacturing.
The tunnel oven adopts a three-lane independent conveyor structure, multi-zone temperature control, HEPA filtration airflow design, and intelligent PLC touch screen operation. It is suitable for precision electronic products that require dust control, uniform heating, and automated continuous production.
Application
The Clean Tunnel Oven G-C5000 is widely used for drying and curing processes in precision manufacturing industries, including:
3C Electronics Industry
Mobile phone housings
Electronic product shells
Precision plastic components
Electronic assemblies
Adhesive and Dispensing Applications
Glue dispensing curing
Adhesive drying
Electronic encapsulation processes
Protective coating curing
Other Precision Manufacturing
Wire harness components
Control modules
Electronic accessories
Precision industrial parts
Standards & Clean Requirements
FED-STD-209E Cleanroom Classification Standard
GB/T 25915 Cleanroom and Associated Controlled Environment
GB/T 11158 Technical Conditions for Temperature Test Chambers
GB 2423 Environmental Testing Standards for Electrical and Electronic Products
(Applicable standards depend on customer production requirements and validation conditions.)
Technical Specifications
| Item | Specification |
|---|---|
| Model | G-C5000 / FJCO-5000 |
| Equipment Type | Clean Tunnel Oven |
| Power Supply | AC380V 3Ø 50Hz |
| Conveyor Structure | Three independent conveyor lanes |
| Conveyor Speed | 0–0.5m/min adjustable |
| Conveyor Width | 1600mm |
| Conveyor Height | 800±40mm |
| Heating Zone Length | 6 meters |
| Temperature Range | +50℃ to +150℃ |
| Standard Working Temperature | 150℃ |
| Temperature Control Zones | 3 independent zones |
| Temperature Uniformity | ≤±5℃ |
| Temperature Accuracy | ±1℃ |
| Clean Level | Class 1000 |
| Temperature Controller | OMRON PID Controller |
| Heating Control | SSR Solid State Relay Output |
| Temperature Sensor | Armored K-type Thermocouple |
| Temperature Monitoring | Six-channel temperature recorder |
| Airflow Design | Horizontal airflow with HEPA filtration |
| Inner Chamber Material | SUS304 Stainless Steel |
| Outer Chamber Material | SS441 Carbon Steel |
| Insulation Material | 128K High Density Insulation Board |
| Control System | Touch Screen Control |
| Safety System | Emergency stop, over-temperature, overload, leakage protection |
