Clean Tunnel Oven G-C106
The Clean Tunnel Oven G-C106 is a continuous conveyor-type drying and curing oven designed for clean production environments. It adopts a multi-zone heating structure, clean airflow circulation design, and precision temperature control system to provide stable thermal processing performance.
The equipment is equipped with a PET-FILM & COVERLEN conveyor belt, Siemens PLC control system, and optimized hot air circulation structure, ensuring smooth product transportation, uniform heating, and reduced particle contamination. It is suitable for cleanroom production processes in electronics, precision manufacturing, and related industries.
Application
The Clean Tunnel Oven G-C106 is widely used for continuous drying, curing, and heat treatment processes requiring a clean environment.
Typical applications include:
Electronic industry: PCB components, electronic assemblies, semiconductor-related parts, and precision electronic products.
Optoelectronic industry: LCD components, optical products, display modules, and precision parts.
New energy industry: Battery-related components and heat treatment processes.
Industrial manufacturing: Adhesive curing, coating baking, ink drying, and material aging treatment.
Cleanroom production: Thermal processes requiring low dust generation and stable temperature control.
Product Parameters
| Parameter | Specification |
|---|---|
| Equipment Model | G-C106 Clean Tunnel Oven |
| Power Supply | AC380V, 3 Phase, 50Hz |
| Exhaust Capacity | MAX 10.0 m³/min |
| Exhaust Pipe Diameter | Ø100mm × 6PCS |
| Conveyor Speed | 0.3-3.0 m/min adjustable |
| Standard Working Speed | 0.8 m/min |
| Conveyor Type | PET-FILM & COVERLEN conveyor belt |
| Conveyor Belt Width | 1600mm |
| Conveyor Height | 980±20mm from floor |
| Heating Zone Structure | 2000mm per section × 6 sections |
| Heating Zone Length | 12000mm |
| Temperature Range | 40℃-200℃ |
| Normal Operating Temperature | Below 160℃ |
| Maximum Temperature | 200℃ |
| Temperature Uniformity | ≤±3℃ (excluding inlet and outlet areas) |
| External Material | SS41 steel plate with anti-rust treatment and high-temperature powder coating |
| Insulation Material | 128K high-density aluminum silicate insulation cotton |
| Door Seal | High-temperature silicone gasket sealing |
| Heating Element | Medium-wave quartz electric heating tube |
| Temperature Controller | OMRON PID temperature controller |
| Temperature Control Accuracy | ±0.3%FS |
| Temperature Monitoring | Six-channel temperature recorder with USB data export |
| Air Circulation Method | Top-down hot air circulation |
| Conveyor Belt Material | PET-FILM & COVERLEN heat-resistant belt |
| Conveyor Drive System | Reducer motor + inverter + gear chain transmission |
| Conveyor Belt Specification | Teflon conveyor belt, beige color, smooth surface |
| External Surface Temperature | ≤45℃ |
| Upper Cover Opening | Electric cylinder lifting with support rod protection |
| Control System | Siemens PLC + Siemens touchscreen |
| Communication | Compatible with MES system |
| Cleanliness Level | Cleanroom environment |
Features
(1) Cleanroom-Compatible Structure
The inner chamber adopts full argon arc welding, with stainless steel screws used throughout the equipment to reduce particle generation.
(2) Large Heating Capacity Design
The G-C106 uses six heating zones with a total heating length of 12000mm, suitable for continuous production requirements.
(3) Stable Conveyor Operation
The conveyor system ensures smooth product transportation without vibration, jamming, contamination, or surface damage.
(4) Uniform Temperature Distribution
The optimized airflow design provides downward hot air circulation, improving heating consistency throughout the oven chamber.
(5) Precise Temperature Control
The OMRON PID temperature controller combined with SSR output provides accurate temperature regulation and stable operation.
(6) Energy-Saving Insulation System
The 128K high-density aluminum silicate insulation material effectively reduces heat loss and improves energy efficiency.
(7) Intelligent Control Capability
Equipped with Siemens PLC and touchscreen operation, the oven supports MES system integration for automated production management.
(8) Flexible Conveyor Configuration
The conveyor belt width, structure, and production parameters can be customized according to different product requirements.
