Nylon Plate Heating Tunnel Oven

The Nylon Plate Heating Tunnel Oven is a continuous industrial heating equipment specially designed for nylon (PA) plates and sheets for continuous preheating, stress-relief annealing, and drying processes.The equipment uses a conveyor system (such as chain conveyors or mesh belts) to transport nylon plates through the tunnel chamber. Through hot air circulation heating or far-infrared radiation heating, the plates are heated uniformly to prevent deformation during subsequent machining processes and improve dimensional stability.

Applications

Stress Relief Treatment

Used for annealing extruded or cast nylon plates before machining processes such as cutting and engraving, reducing internal stress and preventing cracking, warping, or deformation during processing.

Preheating for Thermal Forming

Used for uniform softening and preheating of nylon plates before:

Hot pressing

Stamping

Bending and forming processes

Moisture Removal and Drying

Since nylon has strong moisture absorption properties, the equipment is used for deep drying before machining to improve the physical properties and processing stability of finished products.

Standards

The equipment manufacturing and safety design generally comply with the following standards:

GB/T 10067.1

Basic Technical Requirements for Industrial Electric Heating Equipment

GB 5226.1

Safety of Machinery — Electrical Equipment of Machines, Part 1: General Requirements

JB/T 7629

Design and Installation Specification for Refractory Fiber Furnace Linings

Environmental Protection Standards

When exhaust emissions are generated during operation, the equipment shall comply with relevant national and local industrial VOC and exhaust emission standards.

Features

Precise Temperature Control

Adopts multi-section independent PID digital intelligent temperature control, with temperature uniformity controlled within ±1°C to ±2°C, effectively preventing overheating and yellowing of nylon materials.

Uniform Heating Performance

Equipped with high-temperature-resistant long-shaft circulation fans for forced hot air circulation, or directional far-infrared radiation heating, ensuring consistent heating on both the upper and lower surfaces of nylon plates.

High Efficiency and Energy Saving

The furnace body uses high-density aluminum silicate fiber insulation cotton, which provides excellent thermal insulation, reduces external surface temperature, minimizes heat loss, and significantly reduces energy consumption compared with conventional ovens.

Continuous Production Operation

The conveyor speed adopts variable-frequency stepless adjustment, allowing seamless connection with upstream extrusion processes and downstream machining production lines.
