Goggles Puncture Resistance Testing Machine
Standard
- ECE R22.05 (UN/ECE regulation for motorcycle helmet safety and puncture resistance)
- EN 1077 (Alpine ski helmets – Requirements for sharp-object impact resistance)
- ISO 10256-3 (Headgear testing – Resistance to penetration by sharp objects)
Product Advantages
- Dynamic Impact Simulation
- 3kg sharp-edged hammer: 60° angle attack replicates real-world penetrative threats.
- Adjustable drop height: 1,000–3,000mm range for variable energy testing (29.4J–88.2J).
- Precision Engineering
- Electromagnetic release: Ensures repeatable impact initiation (±1mm height accuracy).
- Anodized aluminum guide tube: Corrosion-resistant with 50,000+ cycle lifespan.
- Universal Compatibility
- Quick-adjust headframe: Fits EN 168 goggle frames and EN 960 helmets (XS–XXL).
- Interchangeable anvils: Tests flat goggles and curved helmet visors.
- Safety First Design
- Overload protection: Halts tests if forces exceed 10kN (50% safety margin).
- Emergency stop: Instantly retracts hammer during malfunctions.
- Data-Driven Compliance
- Automated reporting: Generates ECE R22.05/EN 1077-compliant certificates.
- Historical data review: Compares up to 10,000 tests via cloud-connected software.
Product Features
Impact System
- Sharp-Edged Hammer:
- 3kg stainless steel mass: 60° attack angle (adjustable in 1° increments).
- Hardened steel tip: 1.5mm radius, 60 HRC hardness.
- Guide Tube:
- High-strength aluminum: Anodized finish with laser-engraved height markers.
- Low-friction bearing: Ensures vertical hammer motion (0.05mm deviation).
Headform Assembly
- Adjustable Frame:
- Quick-release clamps: Secures goggles/helmets in <10 seconds.
- 360° rotation: Tests multiple impact angles (0–360°).
Control System
- HMI Interface: 7" touchscreen with multi-language support (EN/DE/ZH/ES/FR).
- Manual Lifting: Smooth crank operation for precise height adjustment.
Safety Systems
- Interlocked enclosure: Prevents access during testing (Category 4 safety rating).
- Auto-eject mechanism: Retracts hammer if misalignment detected.
Technical Parameters
| Specification | Details |
|---|---|
| Impact Height Range | 1,000–3,000mm (adjustable in 100mm increments) |
| Hammer Mass/Angle | 3kg / 60° (adjustable 0–90°) |
| Headform Compatibility | EN 168 goggles, EN 960 helmets (XS–XXL) |
| Guide Tube Material | Anodized aluminum (50mm diameter) |
| Force Capacity | 10kN (±0.5% accuracy) |
| Power Requirements | 220V/50Hz, 500W (single-phase) |
| Footprint | 800mm (L) x 600mm (W) x 3,200mm (H) |
| Weight | 120kg (net) / 150kg (with accessories) |
Accessories Included
- Headform Kit – EN 168 goggle frame and EN 960 helmet headforms.
- Calibration Tools – NIST-traceable force gauge and laser interferometer.
- Anvil Set – Flat and curved anvils for goggle/helmet testing.
- Software License – Lifetime access to ImpactPro (cloud-connected with API for integration with QMS systems).
- Installation & Training – On-site setup by certified engineers + 8hrs virtual training for operators.
- Documentation – Multilingual user manual and ECE R22.05 compliance guide.
Goggles Puncture Resistance Testing Machine Display:
