Cosmetic Bottle Drying Oven
The Cosmetic Bottle Drying Oven is a high-efficiency drying equipment specially designed for cosmetic packaging containers, such as glass bottles, plastic bottles, tubes, ointment jars, and other containers after cleaning. The equipment adopts an advanced hot air circulation system and precise temperature control technology to quickly and thoroughly remove residual moisture inside and outside the containers, ensuring that the packaging materials meet clean, dry, and dust-free standards. It fully complies with the strict requirements of cosmetic GMP production regulations.
Applications
Efficient Moisture Removal:
Quickly dries various cosmetic packaging containers after cleaning.
High-Temperature Sterilization:
Provides thermal sterilization function to reduce the initial microbial load on containers.
Prevention of Secondary Contamination:
Drying is carried out in a closed and clean environment to prevent secondary contamination caused by airborne dust.
Production Line Integration:
Commonly used as a key connecting process between cosmetic bottle washing lines and filling lines.
Technical Specifications
| Parameter | Specification |
|---|---|
| Overall Dimensions (mm) | L15100 × W1790 × H1480 |
| Inner Chamber Dimensions (mm) | L9800 × W1590 × H440 |
| External Shell Material | Cold-rolled steel plate with anti-rust treatment and surface painting |
| Inner Chamber Material | Stainless steel plate, easy to clean and corrosion-resistant |
| Temperature Range | Room temperature to 150℃ (adjustable) |
| Thermal Insulation | High-temperature resistant, high-density premium aluminum silicate wool insulation layer (100mm thickness) |
| Heating Rate | 6–8℃/min (empty chamber test) |
| Temperature Accuracy | ±1℃ |
| Conveyor System | Stainless steel curved plate chain + customized plate chain conveyor system + roller conveyor system |
| Control System | Temperature control system adopts Omron high-precision intelligent controller with automatic temperature control and constant temperature maintenance. Equipped with K-type sensor and functions including PID auto-tuning, automatic constant temperature control, timing function, automatic alarm and power-off after reaching the preset temperature/time, over-temperature power-off protection, temperature monitoring, and leakage protection circuit breaker |
Features
Uniform Heating:
Specially designed hot air circulation duct system ensures minimal temperature difference at different positions inside the oven, providing uniform drying performance.
High Cleanliness:
Built-in high-efficiency HEPA filter ensures that the air entering the drying chamber is clean and free from dust contamination.
Wide Material Compatibility:
Intelligent multi-stage temperature control allows the equipment to handle both high-temperature-resistant glass bottles and low-melting-point plastic bottles.
Energy Efficient:
High-density insulation rock wool layer reduces heat loss, significantly lowering energy consumption during operation.
