Sandblasting robot protective clothing

Sandblasting robot protective clothing

Skype / Email



Product advantages:

Impact resista,High strength,Dustproof,Wear resistan;


Application industry:

Grinding,Metal Fine,Parts processing,Glass manufactory,Electroplating,Workpiece,Finishing process;


Design advantage:

Digital remote design,No field measurement required,Short supply cycle,High precision design,Only 2D & 3D digital analog, on-site video and pipeline trend are required.;


Product Introduction:

The product is made of high density impregnated composite material and hot-pressing sealant technology.

It has good airproof, dustproof, impact resistance, high strength and wear resistance, and can withstand the impact of high-speed pellet/grinding sand with a speed of 200 m/s.

It is applied to pre-treatment of electroplating, cleaning of workpieces in foundry, stamping and welding workshops, grinding and polishing workplaces in glass manufacturing and finishing workshops.


Material parameters:

High Density Rubber-impregnated Wear-Resistant Composites

The proprietary patented product, which is made by immersion, gluing and vulcanization process, has the advantages of high strength, wear resistance and tear resistance. It has large thickness and can effectively alleviate the impact of external forces.

Flame retardant nylon buckle

The flame retardant properties of the buckle and burr both reach grade B1 and have good tear resistance.

Flame retardant elastic band

It has good flame retardancy, high strength and elongation ratio of more than 1:2.5. It is not easy to fatigue under the action of external forces for a long time. Flame-retardant sewing thread: The suture is made of aramid 1414 fiber. It has high strength and good toughness. The limiting oxygen index is more than 28. It can effectively enhance the sutur


Material NumberWeight (g/m²)Thickness (mm)Tensile Strength (MPa)Elongation at BreakTear Strength (kN/m)Abrasion Resistance
CY-RM01553.80.56983.112%201Mass Loss 32mg


User pain point:

Existing Problems:Fast impact speed,Strong impact,High impact frequency,Multidirectional impact;

User loss:Robot damage,Workpiece Damage,High quality product rate,High maintenance cost;


Product details:

Base hem:For the base design can cover a large area of skirt pendulum, fully prevent the pills into the base and the joint of the axle, beautiful appearance.

Side seam nylon buckle:It extends along the side of the robot to facilitate the wearing and tearing of protective clothing.

Pipeline suspension buckle and pendulum elastic belt:Pipeline suspension buckle is added around the arm to fix the pipeline in all directions. A ring of elastic belt is arranged on the hem to fix the protective clothing and prevent the pellets from entering the inside of the robot.

Radial elastic band:Setting multi-channel elastic band in the position where the robot has a larger motion range can help the protective clothing to match the rotation range of the robot by self-expansion without interference.


Note:QINSUN is very in place for textile testing and quality control,we have our own textile testing lab. Our textile testing equipment and testing methods are in the leading position in the industry. We have passed the textile testing certification and iso textile testing standards issued by a number of testing,We can provide textile testing equipment pdf manual. Sufficient inventory, big discounts, limited time promotion, Order now!
