Multilayer geotextile single-layer thickness tester

Multilayer geotextile single-layer thickness tester

Skype / Email



Scope of application:

The multi-layer sample is mechanically separated and the thickness of each single layer of the sample is measured under the specified pressure


Meet the standard:

GB/T17598-1998, etc.


Instrument features:

Thickened upper and lower rectangular plate, can withstand large pressure without deformation;

Straight sliding copper sleeve, smooth plate movement, to ensure the parallelism of the upper and lower plates;

Hand-operated lifting mechanism, maximum force value 1.8T, stable force value, can be fixed on any stroke,

Digital display measuring calipers for easy reading.


Technical parameters:

Rectangular plate thickness 30mm

Travel 0——120mm

Maximum pressure 300kPa

Measuring range 0——200mm

Index value 0.01mm

Point wire φ0.05mm, length 20mm

Isolation plate thickness 2mm

Dimensions: 430*210*510mm

It weighs about 80kg


Standard configuration:

1. One host

2. 1 vernier caliper

3. 1 special wrench

4. Product packing list 1 copy

5. 1 copy of product manual

6. Product tag certificate 1 copy




Note:QINSUN is very in place for textile testing and quality control,we have our own textile testing lab. Our textile testing equipment and testing methods are in the leading position in the industry. We have passed the textile testing certification and iso textile testing standards issued by a number of testing,We can provide textile testing equipment pdf manual. Sufficient inventory, big discounts, limited time promotion, Order now!
