Humidifying Bottle Performance Tester

Main Uses

The humidifier bottle performance tester is mainly used to detect various properties of humidifier bottles, including but not limited to leakage, pressure - resistance, humidification output, and overflow. This instrument can ensure the safety and effectiveness of humidifier bottles during use, and it is an important tool for the quality inspection of medical oxygen humidifiers.

Compliance Standards

YY/T 1610 - 2018

Product Advantages:

The Humidifying Bottle Performance Tester offers several advantages for evaluating medical humidifier bottles:

Specific Application: Designed precisely for medical oxygen humidifier bottles, ensuring relevant and accurate testing of critical properties for this specific medical device component.

Comprehensive Testing: Capable of evaluating multiple essential properties (leakage, pressure, humidification, overflow) in one instrument.

Ensures Patient Safety: Directly contributes to ensuring the safety and reliability of medical oxygen therapy equipment by verifying bottle performance.

Standard Compliant: Meets the requirements of YY/T 1610 - 2018. facilitating compliance with medical device regulations and quality standards.

Quantitative Results: Provides objective, numerical data for each tested property.

Streamlined Quality Control: An efficient tool for quality inspection in a manufacturing environment.

User-Friendly Operation: Advanced features like touch screens, digital presets, and potentially printing functions (depending on the model) enhance usability and efficiency.

Technical Parameters

Working Range: Usually between 0 and 1000KPa (Some models may offer higher pressure options, such as 2000KPa or 2500KPa). Flow Accuracy: ±1%, ensuring the accuracy of testing. Power Supply: Generally 220V, 5A, 50Hz. Instrument Operating Voltage: Usually 220V. Air Source Requirements: Adjustable from 0 to 2MPa. The user needs to provide the air source. Main Unit Dimensions: Dimensions may vary depending on the model. For example, the dimensions of some models are 570×400×200mm (Length×Width×Height). Other Functions: Some advanced - model humidifier bottle performance testers may also have features such as micro - computer control, large touch - screen display, Chinese menu settings, digital preset test flow, and printing function, making the operation more intuitive and convenient.
