RC809 Dissolution Tester

RC809 dissolution tester, performance indicators in line with the 2020 edition of the Chinese Pharmacopoeia requirements. In order to ensure the basic functions of the original dissolution tester, the instrument has added the functions of automatic dosing, single-cup temperature measurement, automatic sampling, etc. It adopts the control mode, and strives to make the whole machine run stably and reliably, which is the high-end instrument in the dissolution series products.

Performance features:

◎ 8-channel temperature monitoring inside the cup. ◎ Automatic lifting of sampling needle and automatic positioning of sampling height.

◎ Can be connected to the P series autosampler, remote control operation, a screen to complete all operations.

◎ Head with integral sealing cup cover, can effectively prevent evaporation of dissolved media, head electric lift (8 paddles / baskets synchronized lift), each paddle / basket rod can be manually disassembled individually. The paddle and basket pole are automatically set at the right height.

◎ Adopt 7-inch large LCD touch screen, easy to operate and understand.

◎ The instrument is connected to the server through the network, connected to the LIMS system, you can choose to log in to the system in both offline and network applications.

◎ The instrument system is equipped with access control rights management function, audit trail, lock screen, data backup, etc. in line with the 2020 edition of the Pharmacopoeia of the People's Republic of China and the provisions of the national industry standards and requirements related to data integrity.

◎ There are three levels of user level management rights, with audit trail function.

◎ With low temperature alarm (<3℃), high temperature alarm (>47℃) and water shortage protection function.

◎ Specially designed automatic dosage device to realize synchronous dosage in paddle method experiment.

◎ Optional micro-printer to print the experimental records (including time, temperature, speed and other test data).

◎ Optional full-data high-precision dissolution cups, each dissolution cup with 3D scanning of the certification report, high-precision dissolution cups with more accurate internal dimensions, spherical radius structure to ensure the accuracy and repeatability of the dissolution experiment.

  Technical indicators:

◎ Stirring paddle and rotating basket specifications in accordance with the Pharmacopoeia regulations

◎ Stirring paddle swinging amplitude: ≤0.5mm

The swinging amplitude of rotary basket: ≤1.0mm.

◎ The deviation of the rotating rod from the axis of the dissolving cup: ≤1.0mm

Speed range: (5-250) rpm

Speed resolution: 1 rpm

Speed stabilization error: ≤±1%.

Temperature adjustment range: 5.0 (room temperature-45.0℃)

Temperature resolution: 0.1℃ ◎ Temperature control error: ≤±1

Temperature control error: ≤ ± 0.2 ℃

◎ Working noise: <60db

◎ Environmental conditions: ambient temperature 5-37 ℃, relative humidity ≤ 80

◎ Safety performance: in line with national industry standards, with self-test and automatic protection function

Power supply: 220V, 50Hz, 10A.
