ICI Pilling Testing Machine

ICI Pilling Testing Machine

Pilling test result:

To assess the test piece according to the visual description. If the test piece stands between two rating, which should be recorded 1/2 rating.

The teat result is the average of all test piece rating, if the average is not an integer, the number should be modified about 1/2 rating to the nearest rating.

Pilling test piece preparation:

Rolling case fabric pilling tester is cut from the fabric of size 125mm*125mm, each of them should be marked the reverse side and lengthways side. We need to test both of sides of the sample when the front and back side is not obvious. In addition, we need to cut the same size piece from fabric as compared with the test piece.

ICI Pilling Box Product Information:

1.Equipped with four pilling Boxes;

2.With the function of Adj;

3.Optional speeds of 20, 30, 40, 45, 50, 60, 65 and 70 rpm can be chosen arbitrarily;

4.All test parameters are displayed on the LCD delete;

5.Alarm reminding as test ended;

6.Well sealed positions;

7.Automatic pause and caution to safeguard the motor.

Applications:

A universal pilling and snagging tester drives system to rapidly repeat pilling or snagging on fabrics to generate normal wear on samples in a fraction of the time.
Provided with unique controller allowing selection between standard and several optional speed settings.
Programmable reversing function at 30 rpm and test cycle definition facilities.


Product Information:

1.Equipped with four pilling Boxes;

2.With the function of forward and reverse running;

3.Optional speeds of 20, 30, 40, 45, 50, 60, 65 and 70 rpm can be chosen arbitrarily;

4.All test parameters are displayed on the LCD delete;

5.Alarm reminding as test ended;

6.Well sealed positions;

7.Automatic pause and caution to safeguard the motor.




pilling resistance random tumble pilling tester






Note:QINSUN always been committed to innovation and improve product performance and functionality, based on the reasons, the product specifications will be changed accordingly. The above without prior notice, the Company reserves the right to amend the final.
