Single Yarn Strength Tester

Single Yarn Strength Tester
“Yarn strength” indicates the amount of tensile load the yarn can withstand. It is classified as absolute yarn strength and relative yarn strength. Relative yarn strength is used when comparing the strength of a yarn with respect to another one.

Application:
Automatic Single Yarn Strength Tester, to determine the breaking strength and elongation rate of single yarn made of cotton, wool and others up to 6000cN, with air-driven clamps. Fully automatically test up to 20 cops at the same time.

Standards:
ASTM D2256,ISO 2062GB/T 398,GB 5324,GB/T 14344,BS,JIS,AS,CAN/CGSB

Features:
Working pattern is CRE principle, controlled by software running in computer
Automatic feeding of yarn, and automatic clamping for test, fast and without damages to yarn
Fitted with Waste yarn collecting device, to make labs clean
Test up to 20 cops at the same time
Software is offered thus the machine can be controlled by a computer. The built-in printer or an additional printer can print test reports.

Specifications:
Test range 20cN ~ 6000cN
Accuracy ≤ 1% F. S
Sampling range 0 ~ 9m
Pre-tension load 0 ~ 100cN, adjustable
Elongation range 800mm
Gauge length 250mm (stretching rate 220%),
500mm (stretching rate 160%)
Tensile speed 50 ~ 5000mm/min, adjustable

Product parameters:
Weight:140 kg
Power:220 V,50 Hz,0.4~0.8 mPa
Width:450 mm
Depth:550 mm
Height:1600 mm


Note:QINSUN always been committed to innovation and improve product performance and functionality, based on the reasons, the product specifications will be changed accordingly. The above without prior notice, the Company reserves the right to amend the final.
