Oxygen Index Test Apparatus

Oxygen Index Test Apparatus
 (Limiting) Oxygen Index Test Apparatus

Testing Standards:
 ISO 4589-2, ASTM D2863, GB/T 2406, GB/T 5454

Applications:
This Oxygen Index Tester is used to determine the lowest oxygen density that tested materials keep steady burning under oxygen and nitrogen mixed gas.

Product Information:

Oxygen Index Test Apparatus Features:
1. Used to determine the lowest oxygen density that tested materials keep steady burning under oxygen and nitrogen mixed gas.
2. Utilizing the latest oxygen analyzer technology, the unit provides a stable, digital readout of oxygen concentration to ± 0.1%.
3. A heavy duty Pyrex chimney is provided, along with two types of sample holder:
A. For non-self-supporting sheet samples (e.g. textiles, films, papers, etc.) Sample size: 150 × 37.5 mm and up to 12 mm thick.
B. Self-supporting rod samples (e.g. plastics, wood, etc.). Sample size: 150 mm length and up to 10 mm diameter.
4. Automatic calibration.
5. Digital selection of oxygen concentration by push-button control.
6. Adjustment of oxygen and nitrogen flow is automatic to achieve the desired oxygen concentration.
7. Digital Display: Instrument status, oxygen concentration, flow rate, chimney temperature, elapsed time.
8. All necessary control valves, flowmeters and filters are built in and the instrument is easy to use.
9. The apparatus is supplied complete with a burner assembly and instruction manual..
10. Weight: 45kg.
11. Dimensions: 460mm(W)×410mm(L)×780mm (H).

Product Display

Note:QINSUN always been committed to innovation and improve product performance and functionality, based on the reasons, the product specifications will be changed accordingly. The above without prior notice, the Company reserves the right to amend the final.
