Fabric Ultraviolet Tester

Fabric Ultraviolet Tester
The Tester is used to determine the UV transmittance and anti-ultraviolet performance of textiles. You can directly obtain the UV protection factor of textiles UPF.

1. BS 79141998 Method of test for penetration of erythemally weighted solar ultraviolet radiation through clothing fabrics.
2. AS/NZS 43991996 Sun protective clothing- Evaluation and classification.
3. AATCC 183 Transmittance or blocking of erythemally weighted ultraviolet radiation through fabrics.
4. BS EN 13758-1 Textiles -  Solar UV protective properties-Part1:Method of test for apparel fabrics.
5. GB/T18830 Textiles—Evaluation for solar ultraviolet radiation protective properties.

Items Parameters
Transmittance   0~100%±0.01%
UPF 0~100
Wavelength Range 280-400nm±0.5nm
Wavelength repeatability 0.25nm
Date break 1nm-5nm, adjustable
Slit width ≤5nm
Optical system 0/d
Sample beam diameter 10mm
Power AC220V50 Hz 100W
Dimension 285×500×500mm
Weight 20kg



Note:QINSUN always been committed to innovation and improve product performance and functionality, based on the reasons, the product specifications will be changed accordingly. The above without prior notice, the Company reserves the right to amend the final.
